BC4-1810 Homework, Wilco Wilbrink
- This topic has 67 replies, 15 voices, and was last updated 7 years, 10 months ago by
.
-
Here’s my homework thread for October Live Class – Shading & Lightning in blender.
Have a great time everyone!
Homework – Week 1 – Part 1:
I made this exercise some time ago. I added stickers to some decals to it. This is the end result:
-edit- And here’s the blendfile (since I forgot): ToyTruck (with packed textures).blend
Hey, thanx!
(images will follow in a few moments)
1. To add stickers I do the following: First I load the picture in the UV/Image Editor:
2. Then I select the faces that I want to use for the sticker:
3. I press U to UV-unwrap the selected faces. I use the option Project from View (So the view must be aligned correctly):
4. Then I name the new UV-map in the Data tab from the Properties Window:
5. I setup the following node setup (look at the bottom (yellow) framed nodes). The first node chooses the UV-map. Don’t forget to choose the correct image from the dropdown menu in the Image-Texture node:
6. I align the unwrapped faces in the UV/Image Editor, while keeping an eye at the 3D View:
I hope this explained it a bit. 😃
